Structural steel painting and coatings

Structural steel painting for beams, columns, stairwells, towers, and support steel in plants, warehouses, garages, and communication sites. Prepped to the spec and coated in layers that last.

Overview

Protecting the frame

Structural steel holds the building up, so a coating failure here isn’t cosmetic. Moisture, chemical vapors, salt air, and temperature swings start rust at edges, welds, and connections, and once it starts, it spreads. The fix is a coating system that keeps oxygen, water, and contaminants off the steel, put on over a properly prepared surface.

The usual system

Most structural steel gets three layers. A zinc-rich primer protects the steel even where the coating gets nicked. An epoxy coat adds a hard, chemical-resistant film. A polyurethane or polysiloxane topcoat holds its color and gloss in the sun. Interior steel in a dry building can take a lighter system. A light finish also brightens the inside of a plant, and the topcoat can carry your safety color codes.

Prep, film, and inspection

Rust, mill scale, and contaminants come off first, by abrasive blasting or power tools, to the standard in the spec, such as SSPC-SP 10 or NACE No. 2. Where blasting is needed, we coordinate it and oversee it as part of the job. We monitor film thickness, coverage, and cure as each coat goes on, and the work is inspected before we call it done.

Steel in hard places

Structural steel is rarely easy to get to. At the Sutro Tower in San Francisco, 1,000 feet tall, crews climbed into the tower’s legs in full harnesses to coat the steel inside, working in the breaks in the fog. One team prepped and a second followed right behind with a rust-inhibiting epoxy, so the bare steel spent as little time as possible in the damp air. On the coast, we coated Green Diamond’s 160-foot wood-chip loading tower and all of its supporting steel. At Westfield’s Fashion Square in Sherman Oaks, we prepped and painted the parking garage’s steel supports, columns, and stairwells.

Projects

Structural steel projects

  • San Francisco’s Iconic Sutro Tower
    Structural steel coatingsSan Francisco’s Iconic Sutro Tower
    The Sutro Tower in San Francisco is a unique, impressive structure, standing at 1,000…
  • Westfield – Fashion Square Mall – Parking Garage
    Structural steel coatingsWestfield – Fashion Square Mall – Parking Garage
    Our team has worked with Westfield on numerous mall projects over a 15+ year period.
  • Orange County Water District
    Structural steel coatingsOrange County Water District
    We provided steel structural coatings for the Orange County Water Districts water catch…

FAQ

Common questions

More FAQs
What paint is used on structural steel?

Usually a system, not a single paint: a zinc-rich primer, an epoxy middle coat, and a polyurethane or polysiloxane topcoat on steel that sees sun. Interior steel in a dry building can take a lighter system, such as an acrylic or a direct-to-metal coating. The spec and the exposure decide.

Can you paint steel in a garage or building that stays open?

Yes. We phase the work, contain dust and overspray, and schedule around tenants and traffic: nights, weekends, between shifts, or one level at a time.

Do your crews work at height?

Yes. Our crews are trained in fall protection, aerial work platforms, and swing stages. At the Sutro Tower they worked inside the tower’s legs, tied off to the structure, with daily safety checks and a safety director on site.
